| Frame | 6061 Aluminum w/Custom Formed T/T & D/T, w/Replaceable
Derailleur Hanger, XS-S:27.5”, M-XL:29”, Internal Cable Routing |
| Rear Shock | n/a |
| Fork | Zoom 565D, 80mm, XS-S:27.5”, M-XL:29” |
| Headset | Threadless Zero Stack, 1-1/8'' |
| Rims | Aluminum Disc Double Wall, XS-S: 27.5x32H, M-XL: 29x32H |
| Hubs, Front | Aluminum Disc w/CNC Rotor Flange, QR |
| Hubs, Rear | Aluminum Disc w/CNC Rotor Flange, QR, Cassette |
| Tires | Kenda Saber, XS-S: 27.5x2.2, M-XL: 29x2.2'' |
| Spokes | 14G Black 32x32 |
| Derailleur, Front | |
| Derailleur, Rear | S-Ride, RD-M300C, 8-Speed |
| Shifters | S-Ride, SL-M300C, 8-Speed |
| Chain | KMC Z8.3 |
| Crankset | Samox Forged, 30T Narrow/Wide C/R, XS-S:170, M-XL:175 |
| BB | Cartridge Bearing |
| Cassette | S-Ride CS-M20008 11-42T, 8-Speed |
| Pedals | Resin ATB Platform w/DU Bearings |
| Seatpost | KHS Aluminum Micro-Adjust 31.6mm |
| Saddle | KHS Sport |
| Handlebar | Aluminum Riser, 31.8, 720x20mm, Ladies:680mm |
| Stem | Aluminum Threadless 4-bolt, 6-degree, 31.8, XS-S:60mm,
M-L:75mm, XL:90mm |
| Grips | KHS Sport |
| Brake Levers | Aluminum Linear Pull, 2.5F |
| Brakes | Radius Cable Disc BR-CX7, 180/160mm Rotors w/ABS System Click for more information about BrakeSafe |
| Color | Black, Silver; Ladies: Mid Blue, Dark Gray |
| Frame Size | 27.5”=XS/13, S/15, 29”=M/17,L/19, XL/21
Ladies 27.5”=XS/13, S/15, 29”=M/17 |
